Type A    Post Terminal Strip Heater
Terminals are provided at one end across width.  Facilitates wiring for making connections
coming from one end.  Available in width 2" and wider.
Strip Heater Styles
Strip Heater Styles
Type G    Strip Heater Metal Braid Leads one end.
For extra protection and strength leads are covered with stainless steel metal braid.  Leads
are internally connected and exit one end for ease of wiring.  Available in 1" and wider.
Type F    Strip Heater Leads off top one end.
Leads exit off top through a bump on one side.  Leads are fiberglass insulated 12" long.
Rated at 250 deg. C, 600V.  This termination is good where there is no room for leads from
the edge of the heater.
Type E    Strip Heater Lead each end.
Fiberglass insulated leads are internally connected and exit from each end for ease of
wiring.  Lead length is 12" and are rated to 250 deg., 600V. mounting holes can be provided
to contour from the path of leads or vice versa.
Type D    Strip Heater Leads one end.
Lead wire is internally connected exiting from one end.  Standard lead length is 12" and is
rated to 250 deg. C, 600V.  Available in width 1" and wider.
Type C    Strip Heater Post Terminal on one end.
Terminals are provided in line parallel to the length of the heater.  This provides ease of
wiring and making parallel connections.
Type B    Strip Heater Post Terminals each end.
This terminal arrangement is good when heaters have to be connected in parallel and the
wiring is coming from each end.  Available in width 3/4" and wider.
Type H    Strip Heater Metal Braid Leads each end.
Leads are at each end and are protected by stainless steel metal braid.  Lead length is 12"
each end.  Rated at 250 deg. C, 600V.  Available in 3/4" and wider.
Type J     Strip Heater Armor Cable Leads.
Armor conduit exiting from one end protects leads.  10" conduit is standard with 2" leads
extending beyond.
Click here to go to the
Conversion Data page.
Need more information?  Contact Us
Home        Line Card        Band Heaters        Cartridge Heaters        Cast-In Heaters        Rubber Silicone        Mini Coil       Strip Heaters       Mercury Relays       Thermocouples
Strip heaters can be manufactured in a wide assortment of lead and termination styles.  Contact up with your industrial
application to determine the strip heater style that would best suit your needs.
